VM55B-R – Razor Thin Bezel LCD Video Wall for Business
Razor-thin 0.44mm even bezel design delivers one immersive, seamless image.
Wide viewing angles enable clear image presentation for more viewers in large spaces 700 nit brightness and non-glare panel provide high visibility 24/7.
Picture enhancement technology delivers optimized visuals.
1. Seamless video walls with razor-thin bezels
2. Nearly invisible 0.44 mm bezel
3. View content from any angle
4. Image enhancement technology
5. Modern, slim design
6. Vibrant images 24/7
7. Convenient mobile calibration
8. Comprehensive calibration
9. Advanced UHD presentation
10. Industry standard certified
11. Intuitive all-in-one operations
Display
Screen Size : 55″
Type : IPS
Resolution : 1920×1080
Pixel Pitch : 0.63X0.63
Active Display Area : 1209.6(H) x 680.3(V)
Aspect Ratio : (16:9)
Brightness : 500 nit
Contrast Ratio (Typical) : 1100:1
Operation Hours : 24/7
Color Gamut : 72
Haze : 28%
Orientation : Landscape/Portrait
Connectivity
Input
VIDEO:HDMI 2.0 (2)/DVI-D, Display Port 1.2
AUDIO: Stereo mini Jack
USB: 2.0 x 1
Output
VIDEO: DP1.2(Loop-out)
AUDIO: Stereo mini Jack
Power
Power Supply : AC 100 – 240 V, 50/60 Hz
Power Consumption (Standby) : Max: 270 / Typical: 165
Sleep Mode: less than 0.5W
Environmental Conditions
Operating Temperature : 0℃~ 40℃
Operating Humidity : 10~80%
Features
Special
HARDWARE: ACM Support(Advanced Color Management), Temperature Sensor, Video Wall Daisy Chain(10×10), DP 1.2 Digital Daisy Chain(Supporting UHD Resolution, HDCP support), Clock Battery(168hrs Clock Keeping).
SOFTWARE: Auto Source Switching & Recovery, RS232C/RJ45 MD Button Lock, Smart F/W update.
24/7 Operation : Yes
System On Chip : Yes
Dimensions
Bezel Width (mm) : Yes
Without Stand (W x H x D) : 1211.0×681.7×69.9
Packaging (W x H x D) : 1414x844x257
Bezel Width : 0.44mm
Bezel-to-Bezel : 0.88mm
Weight
Product Weight : 16.8kg
Package Weight : 25.1kg
Accessories
Included in Box :
Quick Setup Guide
Warranty Card
Power Cord
RS232C(IN) Gender (Stereo to DB-9)
Remote Controller + Batteries
DP cable
Optional Wall Mount Kit : WMN-55VD
Mechanical Specs
VESA Mount : 600 x 400
Certification
Safety : 60950-1
EMC : Class A
IP Rating : IP5x
